1998 Yamaha Banshee YFZ 350
Twin
This project
began as a way for me to get over my dirt bike boredom. I had been
riding motorcross bikes all my life and started to get bored with
them. I decided to give quads a try as I'd always wanted one but
never could afford it. I sold my KTM 250SX and bought this 1998
Banshee in March 2005. When I got it, the only mods where some
worn out RAZR tires and a proflow filter setup. On the way home from
picking it up, I said I would ride it for a year before I started modding
it. 3 weeks later I had a ton of items for it I'd purchased on eBay
and Project Banshee was
officially underway...
Here is all the
information from when I purchased the quad to it's current state.
Stats
Stock
/Modified
Engine: 350cc
Twin Cylinder 2-Stroke
Induction: Airbox
and Panel Filter /
Twin K&N Filters Directly on Carbs Covered by OuterWears
Power:
36hp@6800rpm, 30
lb-ft Torque@4800rpm /
65hp@9800rpm,
48 lb-ft Torque@5700rpm
Exhaust:
Restrictive
Stock Exhaust Pipes and Silencers /
FMF SST Pipes and Silencers
Transmission:
6-Speed Sequential
Rear Gear: 41
Tooth Sprocket
Brakes f/r: 9.5"
disc/disc with Single Piston YFZ450 Calipers
Suspension f/r:
Unequal Length +2+1 Lonestar A Arms,YFZ450 Shocks/SandDragon Swinger,
Stock Axles
Curb Weight:
340lbs
Weight Distribution f/r:
53%/47%
Paint:
Yamaha Blue Tank/Graphics with White Fenders.
Performance
0-60: 6.0 seconds
/
4.1 seconds
Quarter Mile: 15.7 at 73 mph
/ 13.6
at 85 mph (Gear limited)
Top Speed: 73 mph (HP Limited)
/
85 mph (Gear Limited)




 Kill List
'05 Bombardier DS650
'05 Yamaha YFZ450
'06 Yamaha Raptor 700rr
'06 Polaris Predator
'89 Honda TRX 250R (ported, LRD Pipe, 200lb compression, etc.)
'05 Honda CRF 250R
'99 Honda CR 125R
Mods
Engine/Transmission--Ported
Jugs, Noss Design Cool Head w/20cc Domes, Wiseco Pro-Lite .040"
Pistons, Trued & Welded Crank, FMF SST Pipes/Silencers, Bored Stock
Carbs (27.5mm), K&N Pod Filters w/Outerwares,
Boyesen Dual Stage Carbon Fiber Reads, Billet Water Pump/
F.A.S.T Racing Clutch w/LD
Springs, Clutch Pancake Bearing.
Suspension/Steering/Brakes/Tires--Lonestar
+2+1 A Arms, YFZ 450 Shocks, Sandragon Dragontail Swingarm with 250R Style
Carrier / Pep
Steering Stabilizer /
YFZ 450 Calipers,
Stainless Steel Brake Lines, EBC Pads /
Maxxis RAZR Front
Tires, Kenda Knarly Rear Tires, Stock Wheels-Flipped in Rear +2 /
TM DesignWorks Chain
Slider Kit.
Cosmetics--Polished Engine,
Polished Clutch Cover, Anodized Cylinder Jugs, Polished Head, Blue Stator Cover,
Billet Clutch Cover Insert, Shaved Front Fenders, Stainless Steal Fender
Bolts, Stainless Steel Engine Bolts, Stripped Rear Fender Decals, Bling
Racing Kickup Pegs, Trail Tech Torch Lights, AC Racing Bumper, DG Grab
Bar, Tusk Polished Nerf Bars, Flush Valve Stems, Anodized Axle Lock Nut,
CR Clutch Perch, Carbon Fiber Look Levers, Flamed Grill Insert.


©
Gustafson 2006
|
